Product Description
The range of AMD series driers is the perfect tool for removing unwanted moisture from compressed air.
AMD driers are highly efficient and compact and achieve excellent performance even where high temperatures exist.
AMD dryers use the ALU DRY aluminium modular heat exchanger which has a vertical flow layout ensuring wet compressed air flows down to the condensate drain.
AMD driers are simply sized to suit the horsepower of the compressor.
- Refrigerant used is R134A
- Pressure Dewpoint 5°C
- Prefilters MUST be used
Direct heat exchange without glycol. Complete with separator and automatic condensate drain. Dew point 5°C (normal conditions). Designed for tropical conditions. Freon R134A to CE standards
Technical data
| LPM/ CFM: | 2500/ 88 |
| Compressor: | 20 HP max power |
| Outlet: | 1" |
| Dimensions: | 37 x 42 x 74 |
| Weight: | 34 kg |
